Protection against rain according to EN 343:2003 – Section 5.1.3.5

Resistance to Water Penetration After Pre-Treatment (Flexing Test)
rain jacket
Testing lab
Physical lab
Legislation
PPE Regulation (EU) 2016/425
Testing standard

N 343:2003 – Section 5.1.3.5

Principle

The principle of EN 343-5.1.3.5 is to assess the water resistance durability of protective clothing materials after undergoing mechanical stress, specifically flexing. It ensures that the material retains its waterproof qualities even after wear and movement, simulating real-life use conditions.

Testing Procedure

1. Pre-treatment by Flexing (Conditioning):

  • The fabric sample is subjected to repeated flexing using a flexing device (e.g., the Bally flexometer or equivalent).
  • The flexing simulates repetitive movements or bending of the fabric during actual use.
  • Standard conditions:
    • Typically 9,000 cycles of flexing (this may vary slightly depending on the device).
    • Performed under standard atmospheric conditions (20±2°C and 65±5% RH).

2. Water Penetration Resistance Test (Post-Flexing):

  • After flexing, the sample is tested for water penetration resistance using a hydrostatic head test (usually based on ISO 811).
  • Water pressure is gradually applied to one side of the fabric.
  • The pressure level at which water penetrates the other side is recorded.
  • This test evaluates how well the fabric retains its waterproof properties after being stressed.

3. Classification:

  • Based on the hydrostatic pressure result, the material is classified under EN 343 waterproofness levels (e.g., Class 1, 2, or 3, with Class 3 being the most resistant).
raincoats

Applications

This section of the standard is essential for evaluating functional rainwear used in tough or demanding environments. Common applications include:

  • Industrial workwear for outdoor jobs (e.g., construction, logistics).
  • Forestry and agricultural clothing, where frequent movement and wet conditions occur.
  • Protective uniforms for emergency and utility services.
  • Military and police rainwear.
  • Outdoor professional gear used by surveyors, engineers, and more.

It ensures that waterproof garments remain effective even after mechanical wear, helping prevent water ingress that could lead to discomfort, hypothermia, or reduced safety.
