Imaging techniques
Centexbel succeeds in imaging four-layer films by combining SEM imaging techniques, EDX and FTIR analysis.
This combination enabled us to characterize the thickness and composition of no less than four layers (PET/ PE/Al/PE).
Hot stage microscope with crossed polarizers
The crystallisation behaviour of a PHBV with softener material as recorded with a hot stage microscope with crossed polarizers.
The paste was heated to different temperatures prior to cooling: maximum temperatures of 165°C, 170°C, 180°C and 180°C during 2 minutes.
The video shows the cooling phase from 120°C to 60°C. In this temperature range the paste solidifies into a film and the growth of crystals can be seen. Higher temperatures result in a smaller amount of larger crystals and the formation of a brittle film. We also observed that the crystallisation behaviour depends on the highest processing temperature and not on the cooling rate.
Discover the hidden beauty of the microscopic world!
Follow @centexbelvkc on Instagram for stunning SEM images revealed every month.
From breathtaking textures to mesmerizing details, get inspired by what you can’t see with the naked eye. Don’t miss a single masterpiece—join us on our journey into the invisible!
Testing
This brochure features a thematically ordered selection of tests performed in our laboratories.
